Vishay VS-40TPS12 40A Phase Control SCR
Vishay VS-40TPS12 40A Phase Control SCR is a silicon controlled rectifier (SCR) that is specifically designed for medium power switching and phase control applications. These devices offer a 1200V maximum repetitive peak reverse voltage (VRRM) with a 35A maximum average on-state current (IT(AV)). The maximum required DC gate current to trigger (IGT) is a low 150mA. The Vishay VS-40TPS12 is a flexible solution for reliable AC power rectification.
Features
- Low IGT
- AEC-Q101 qualified meets JESD 201 class 1A whisker test
- Flexible solution for reliable AC power rectification
- Single SCR circuit configuration
- TO-247AD 3L package
- Peak repetitive reverse voltage up to 1200V
- Easy control peak current at charger power up to reduce passive/electromechanical components
- -40°C to +125°C operating temperature range
- Lead-free, Halogen-free, and RoHS compliant
Applications
- Input rectification crowbar (soft start)
- AC switch in motor control
- UPS
- Renewable energy inverters
- Welding
- Battery charge
Onfographic
