Qorvo CMDx Distributed Driver Amplifiers

Qorvo CMDx Distributed Driver Amplifiers are designed to provide efficiency for gain stages prior to the final power amplifier in a transmitter chain. These CMDx amplifiers are 50Ω matched design that eliminates the need for RF port matching. The CMDx distributed driver amplifiers are RoHS compliant and lead-free. Typical application includes Electronic Warfare (EW), satellite communications, test and measurement, radar, and space.

Features

  • RoHS compliant
  • Lead-free
  •  CMD192/CMD244:
    • Small die size
    • High output power
    • Positive gain slope
    • Ultra-wideband performance
    • Low noise figure
  • CMD192C5/CMD244K5:
    • Pb-free, RoHS compliant, and 5mm x 5mm SMT package
    • High output power
    • Positive gain slope
    • Ultra-wideband performance
    • Low noise figure
  • CMD233:
    • Single positive supply voltage
    • Small die size
    • Low noise figure
    • Wide bandwidth
    • Positive bias
  • CMD233C4:
    • Pb-free, RoHS compliant, and 4 x 4 QFN package
    • Single positive supply voltage
    • Wide bandwidth
    • Low noise figure
    • Positive bias
  • CMD304:
    • Ultra-wideband performance
    • Flat gain response
    • Low power consumption
    • Small die size
  • CMD311P34:
    • Wideband performance
    • High linearity
    • Low current consumption
    • Low noise figure
    • Pb-free, RoHS compliant, and 3 x 3 QFN package
  • CMD317:
    • Wide bandwidth
    • High linearity
    • Low noise figure
    • Single positive supply voltage
    • On-chip bias choke
  • CMD292:
    • Ultra-wideband performance
    • High linearity
    • High output power
    • HMC994 replacement
    • Small die size

Specifications

  • CMD192/CMD192C5:
    • DC to 20GHz frequency range
    • 19.5dB gain
    • 1.9dB noise figure
    • 24.5dBm Output P1dB
    • 26dBm Psat
    • 31dBm Output IP3
    • 5V to 8V input voltage range
    • 200mA current
  • CMD233/CMD233C4:
    • 2 to 20GHz frequency range
    • 9dB gain
    • 4.5dB noise figure
    • 20.5dBm Output P1dB
    • 22dBm Psat
    • 24dBm Output IP3
    • 3V to 6V input voltage range
    • 120mA current
  • CMD244:
    • DC to 24GHz frequency range
    • 18dB gain
    • 2.5dB noise figure
    • 25dBm Output P1dB
    • 26.5dBm Psat
    • 32dBm Output IP3
    • 5V to 8V input voltage range
    • 185mA current
  • CMD244K5:
    • DC to 2OGHz frequency range
    • 17.5dB gain
    • 2.5dB noise figure
    • 25dBm Output P1dB
    • 26.5dBm Psat
    • 31dBm Output IP3
    • 5V to 8V input voltage range
    • 185mA current
  • CMD304:
    • DC to 67GHz frequency range
    • 10dB gain
    • 3dB noise figure
    • 11dBm Output P1dB
    • 14dBm Psat
    • 21dBm Output IP3
    • 3V input voltage
    • 40mA current
  • CMD311P4:
    • DC to 20GHz frequency range
    • 12dB gain
    • 2.5dB noise figure
    • 11dBm Output P1dB
    • 13.5dBm Psat
    • 22dBm Output IP3
    • 3V to 8V input voltage range
    • 40mA current
  • CMD317:
    • 1000MHz to 24000MHz frequency range
    • 16dB gain
    • 3dB noise figure
    • 24dBm Output P1dB
    • 22dBm Output IP3
    • 5V to 8V input voltage range
    • 225mA current
  • CMD292:
    • DC to 30GHz frequency range
    • 13dB gain
    • 3dB noise figure
    • 27dBm Output P1dB
    • 28.5dBm Output IP3
    • 8V to 11V input voltage range
    • 250mA current




Applications

  • Electronic Warfare (EW)
  • Satellite communications (Satcom)
  • Test and measurement
  • Radar
  • Space

Application Notes

Associated Product

CMD2x Distributed Amplifiers

Qorvo CMD2x Distributed Amplifiers

Designed to deliver best-in-class performance and ideal for a wide range of broadband applications.

Learn Moreabout Qorvo CMD2x Distributed Amplifiers View Productsrelated to Qorvo CMD2x Distributed Amplifiers
CMD2x Distributed Power Amplifiers

Qorvo CMD2x Distributed Power Amplifiers

Wideband GaAs MMIC distributed amplifiers die that operate from DC to 20GHz.

Learn Moreabout Qorvo CMD2x Distributed Power Amplifiers View Productsrelated to Qorvo CMD2x Distributed Power Amplifiers
View Results ( 10 ) Page
Dalies Numeris Gamintojo Pavadinimas Aprašymas Duomenų Lapas
CMD311P34 Qorvo RF Stiprintuvas DC-20 GHz Distributed Driver Amplifier
CMD233 Qorvo RF Stiprintuvas 2 - 20 GHz Driver Amplifier
CMD192C5 Qorvo RF Stiprintuvas DC-20 GHz Distributed Driver Amplifier
CMD233C4 Qorvo RF Stiprintuvas 2 - 20 GHz Driver Amplifier
CMD192 Qorvo RF Stiprintuvas DC-20 GHz Distributed Driver Amplifier
CMD304 Qorvo RF Stiprintuvas DC-67 GHz Driver Amplifier
CMD244K5 Qorvo RF Stiprintuvas DC-20 GHz Distributed Driver Amplifier
CMD244 Qorvo RF Stiprintuvas DC-24 GHz Distributed Driver Amp DIE
CMD292 Qorvo RF Stiprintuvas DC-30 GHz PA
CMD317 Qorvo RF Stiprintuvas 1 - 24 GHz Distributed Driver Amplifier
