Amphenol Onanon MagConnect® Rho Circular Connectors

Amphenol Onanon MagConnect^® Rho Circular Connectors feature a unique magnetic safety latch, making them ideal for medical applications where time, precision, and quality are most critical. These connectors offer a 4 to 16 pin capacity, magnetic safety delatching, and intuitive and self-mating options. The MagConnect Rho circular connectors are safe for both low (<12V) and high (>5000V) voltages. These connectors are used in applications with low and high voltages, sensitive EMI, shock and vibration environments, and integration of intelligent electronics. Typical applications include the medical, automotive, aerospace, and industrial sectors.

Features

4 to 16 pin capacity
Intuitive and self-mating
Magnetic safety delatching
Easily add components such as EEPROMs, resistors, and capacitors
EMI/RFI safe

Low (<12V) and high (>5000V) voltage safe
VF/HF/RF safe
Rugged use in outdoor wearables
Customizable for reusable or single-use applications

Applications

Medical
Automotive

Aerospace
Industrial

Specifications

10K minimum mating cycles
Mating forces:
- Magnetic insertion
- 2lbf (minimum) removal
IEC 60601-1 finger safety

Plug cable assembly:
- 26AWG to 50AWG accepted wire gauge range
- 0.272" (maximum) cable jacket OD
- Solder contact termination
0°C to 150°C operating temperature range
